Dodge Journey: Electronically controlled clutch

REMOVAL

NOTE: Rubber coupler is part of the propeller shaft assembly. Removing coupler from propeller shaft will result in vibration/balance issues.

Differential and Driveline
Fig. 95: Removing /Installing Propeller Shaft

1. Make sure transaxle is in neutral (N).

2. Raise vehicle on hoist.

3. Apply alignment index marks (4) on the rear axle flange (5) and rubber coupler (1).

4. Remove three rear propeller shaft rubber coupler to rear axle input flange retaining bolts (3).

5. Slide propeller shaft (2) back off rear axle input flange (5) and move out of the way as needed.

Differential and Driveline
Fig. 96: Electrical Connector At ECC

6. Unplug the electrical connector at the ECC.

7. Remove the mounting bolts at the ECC.

8. Remove the ECC.

INSTALLATION

Differential and Driveline
Fig. 97: Electrical Connector At ECC

1. Make sure transaxle is in Neutral (N) position.

2. Raise vehicle on hoist.

3. Install the ECC.

4. Install the mounting bolts at the ECC and tighten to 60 N.m (44 ft. lbs.).

5. Connect the electrical connector at the ECC.

Differential and Driveline
Fig. 98: Removing /Installing Propeller Shaft

6. Align marks (4) on propeller shaft rubber coupler (1) to rear axle input flange (5).

7. Install three rear propeller shaft to rear axle retaining bolts (3) and tighten to 58 N.m (43 ft. lbs.).

8. Lower vehicle.
