Dodge Journey: Seal, output flange

REMOVAL

Differential and Driveline
Fig. 93: Axle Seal Removal

  1. - SEAL
  2. - SCREWDRIVER

1. Raise vehicle on hoist.

2. Remove rear driveline module.

3. Use suitable screwdriver (2) to remove output seal (1).

INSTALLATION

Differential and Driveline
Fig. 94: Axle Seal Installation

  1. - HANDLE C-4171
  2. - INSTALLER 8493

1. Install output flange seal to differential housing using handle C- 4171A (1) and installer 8493 (2).

2. Install rear driveline module.

3. Check differential assembly fluid level and adjust as required.
